High-Performance Submersible Pump for Large Ponds and Waterfalls
The Teton XPF5200 is a robust vortex submersible pump engineered for demanding pond and waterfall applications. Its direct-drive design and vortex impeller deliver consistent high-volume flow while handling solids up to 3/4" diameter—ideal for ponds with debris, filtration systems, and water circulation projects.
Key Features
- Vortex impeller design for reliable solids handling
- Direct-drive motor for durability and efficiency
- Thermal overload protection
- Threaded NPT discharge for easy installation
- 2-year warranty
Performance Specifications
| Flow Rate (GPH) | 5 ft Head | 10 ft Head | 15 ft Head | 20 ft Head | 25 ft Head | Max Head | Horsepower | Amperage |
|---|---|---|---|---|---|---|---|---|
| 5150 | 5150 | 4550 | 3740 | 3000 | 2040 | 32 ft | 1/2 HP | 5.2 A |
Ideal Applications
Perfect for submersible installation in large ponds, waterfall systems, high-volume filtration setups, and general de-watering projects where reliable performance and solids tolerance are essential.
